Equipment Listing
Primary Equipment
MILLS:
1 - CINCINNATI MILACRON 10 VC 1250, 3 Axis Vertical
N/C Machining Center; 26" x 54" table capacity with 30 tool random
select tool changer; 10 H.P.; spindle speeds from 25 to 4000 RPM's.
1 - YCI SUPERMAX MX1 Vertical Machining Center with
Fanuc 11M Control; 15" x 24" table capacity with 20 tool random
select tool changer; 7-1/2 H.P.; spindle speeds up to 7500 RPM's.
1 - FADAL VMC-15XT Vertical Machining Center, CNC
88 HS Control with graphic CRT; 30" x 16" x 20" travel in
XYZ with 21 station automatic tool changer; 15 H.P.; spindle speeds 150
to 7500 RPM's. Rigid tapping.
1 - FADAL VMC-15XT 4-Axis Vertical Machining Center, CNC
88 HS Control with graphic CRT; 30" x 16" x 20" travel in
XYZ with 21 station automatic tool changer; 15 H.P.; spindle speeds 150
to 7500 RPM's. Rigid tapping.
1 - FADAL VMC-4020A Vertical Machining Center, CNC 88 HS Control with graphic CRT;
40" x 20" x 20" travel in XYZ with 21 station automatic tool changer; 22.5 H.P.; spindle
speeds 150 to 7500 RPM's.; Rigid tapping.
1 - KEMPSMITH #3 HORIZONTAL MILL--13" x 73"
table; speed 25 to 2000 RPM's. spindle drive to 2 H.P.; vertical capacity
22".
4 - BRIDGEPORT VERTICAL MILL--10" X 48"
table; cross and longitudinal 18" x 10" x 36" capacity.
(3 with digital read-outs, .0005 resolution).
ADDITIONAL TOOLING includes Hartford Super Spacers
equipped with a variety of index plates, chucks and face plates. Horizontal
and vertical milling heads, dividing heads, rotary tables, criterion boring
heads and bars, taper attachments, vises and chucks.
HONE:
1 - SUNNEN HONE MBB-1800 Power-Stroked Precision
Honing Machine;
production type, range, .060 to 2.625 x 18" length, capable of honing
bores
with keyways, splines, ports, etc.
LATHE:
1 - HWACHEON HI-ECO 21HS CNC LATHE; Fanuc OTC; 45
degree slant bed; 12 station turret with curvic coupling; maximum swing
22.9"; 20 H.P.; spindle speed 30 to 4000 RPM's.
1 - TARNOW ENGINE LATHE, MODEL TUJ-50M, 31-1/2"
swing; 98" centers; 14 H.P.; 20 to 1600 RPM's; 3 jaw chuck, 4 jaw
chuck, following rest, steady rest, taper attachment, travel dial and Aloris
tool holders.
1 - WEBB ENGINE LATHE, 15" swing, 48"
centers; 7-1/2 H.P.; 50 to 4000 RPM's. 3 jaw chuck, 4 jaw chuck, following
rest, steady rest, taper attachment, travel dial and Aloris tool holders.
TOOLING for the above equipment includes a full
range of colleting systems, threading and taper attachments, soft jaws,
and complete tooling for chucking work.
Secondary Equipment
1 - 400 Amp. T.I.G. Welder, 200 Amp. and 400 Amp.
Torches
1 - Bench Master Punch Press, 4 Ton
2 - Makita Cut-Off Saw
1 - Dual vertical bandsaw with 16" throat
2 - Vibratory deburring machines
1 - Marfred shrink wrap 18" x 24" packaging
machine
1 - Clark Forklift, 2000 pounds
1 - Jib Crane - 2000 pounds
DRILL PRESSES:
1 - 8-Spindle 14" Delta 96; production table,
5/8" capacity with coolant to
each spindle.
2 - Walker-Turner 14" and 17" drill presses.
Inspection Equipment
A separate, fully-equipped Inspection Room, containing
all the necessary gauges and tooling for complete inspection of parts is
maintained and calibrated in accordance with MIL-C-45662A.
Picomm Mark II coordinate measuring machine; 31"
x 18" x 7" Twin probe set-up with complete digital readout, .0002
resolution, x, y, and z axis.
2 - 84 pc. sets certified gauge blocks--accuracy
+.000004/-.000002
Cadillac Height Gages: One 18" and one 12"
with riser block, 30" cap.
24" Mueller Height Gage
24" Mitutoyo Height Gage
18" Mitutoyo Height Gage
1 - 36" x 48" Granite surface plate
2 - 24" x 36" Granite surface plate
2 - 12" x 18" Granite surface plate
1 - Granite Universal Right Angle Master. Accuracy
within .000025
Sunnen PG-400 Size Setting Fixture---calibrated
to +/- .000005 (five millionths)
Sunnen Gage Setting Fixture, Model CF-1126, Range
2" - 6"
Sunnen Gage Setting Fixture, Model CF-502, Range
0 - 2"
Sunnen Precision Hole Gage, Model PG-800-8, .370-1.500,
.00005 graduations
Sunnen Dial Bore Gage, Model GA-2061, 2"-6",
Range .0001 graduations
Sunnen Dial Bore Gage, Model GA-4000, 4.95 - .750,
Range .0001 graduations
Sunnen Dial Bore Gage, Model GR-6000, .740-1.190,
Range .0001 graduations
Sunnen Dial Bore Gage, Model GR-9000, 1.180-2.000,
Range .0001 graduations
Sunnen Bore Gage, 2.000 - 6.000, Range, .0001 graduations
Alina Bore Gage, .750 - 2.000 Range, .0001 graduation
Federal Air Gage with assorted master rings and
probes .00005 graduations
Mueller Inside Groove Diameter Gage, .0005 graduations
Outside Micrometers:
0 - 6" Mitutoyo
6 - 8" Scherr Tumico
6 -12" Starrett
Dial Micrometers:
0 - 1" Etalon .0001 Graduations
1 - 2" Etalon .0001 Graduations
3 - 4" Mitutoyo .0001 Graduations
Blade Micrometers:
0 - 1" Scherr Tumico
1 - 2" Scherr Tumico
2 - 3" Mitutoyo
Ball Micrometer:
0 - 1/2" Starrett
Thread Micrometers:
0 - 1" Tesa Threadmaster with interchangeable
anvil and spindle sets
Flange Micrometers:
0 - 1" Mitutoyo
1 - 1" Lufkin
Depth Micrometers:
0 - 6" Brown and Sharpe
0 - 6" Mitutoyo
12" Mitutoyo Dial Caliper
12" Helios Vernier Caliper
36" Starrett Vernier Caliper
Mauser Universal Bevel Protractor
5" Sine Plate
Bausch and Lomb Microscope
.011 - .060 Gage Pin Set
2 - .060 - .250 Gage Pin Set
2 - .251 - .500 Gage Pin Set
4 - Sets A-Z Drill Blanks
4 - Sets 1/16 - 1/2" Drill Blanks
4 - Sets #1 - #60 Drill Blanks
Various test and travel indicators, .0001, .0005,
and .001 graduations.
Numerous assortment of plug and ring thread gages.
Large assortment of Deltronic and Amalgamated tenth
pins.
MISCELLANEOUS INSPECTION EQUIPMENT includes angle
plates, V-blocks, bench centers, surface roughness gages, magnetic V-blocks,
thread measuring wires, etc.
|
